VISAX MV Metal-clad Switchgear (up to 24kV, 2500A, 25kA) - produced by Schneider Electric Wherever must be distributed and used with maximum availability and reliability, we have the experience and the know-how to offer you the equipment which best meets these needs. To meet today’s demands for quality products, has developed VISAX, an original switchgear concept.
Operation Manual Sample
VISAX is available in a range of designs to meet the diverse needs of small and medium sized installations in the fields of primary power distribution, industry and infrastructure. VISAX perfectly meets users’ key requirements of simplicity, reliability and safety. A New Generation of MV Switchgear VISAX combines the proven benefits of and technology with an innovative rotating disconnector-circuit breaker module in a new simple architecture. VISAX is available with ratings up to 24 kV, 2500 A, 25 kA and is a metal enclosed switchgear in accordance with IEC 62271-200. The rotary circuit breaker — which is directly in line with the busbars and cable connections –also performs the isolating function. All operations can be performed in complete safety from the front panel with the doors closed. Information on the state of all switching elements of the switchboard is ergonomically grouped together on a dedicated control panel.
The clear information display, using status indicators that are an integral part of the circuit breaker and the earthing switch, eliminates any risk of error. VISAX meets IEC standards as well as GOST, CSA and GB specifications.
Reliable Visual Displays VISAX - Reliable visual displays The vertical in-line layout of all elements in the main circuit allows the position of the circuit breaker and earthing switch to be viewed directly from the front of the cubicle. With visible isolating distances on the circuit breaker and earthing switch, there can be absolutely no doubt whether the devices are in the “service”, “isolated” or “earthed” positions, ensuring intrinsically safe operation. There are two single line mimic diagrams on the front of the cubicle. The first directly integrates the position indicators to give a clear visual display of the circuit breaker’s status: open, closed, isolated, in service.
The second gives positive indication of the status of the earthing switch, eliminating any possibility of error, as the position indicator is an integral part of the earthing switch mechanism. Both mimic diagrams are entirely mechanical, and therefore operate even in the event of a power loss of the unit. In addition, the circuit breaker’s rating plate, the operations counter and the status of the spring mechanism are all clearly visible from the front, with the door closed.
